SOLDERING IRON TIP
- Soldering Iron Tip 60W
- 220/240VAC
- Shape : Conical
Price 100 Birr
https://vector4engineering.com/product/soldering-iron-tip/
Address – Megenagna, Zefmesh Grandmall 3rd floor 301
0993802995 Vector/0922787347 Kase
VECTOR FOUR ENGINEERING

TACHOMETER SPEED SENSOR
- Speed Sensor Module LM393 Motor Measuring Comparator Slot Type IR Optocoupler for MCU Arduin0
- The use of imported groove coupler sensor, slot width 5mm.
- The output status indicator light, output high, output low lights.
- Block, high output; No Shelter, Low Output
- Clean signal comparator output, good waveform, more than 15mA driving capability.
- Voltage 3.3V-5V
- Output format: digital switching output (0 and 1)
- Small PCB board size: 3.2cm x 1.4cm.
- Widely used in motor speed detection, pulse counter, etc.
Price 500 Birr
https://vector4engineering.com/product/tachometer/
Address – Megenagna, Zefmesh Grandmall 3rd floor 301
0993802995 Vector/0922787347 Kase
VECTOR FOUR ENGINEERING

DRAG CHAIN R55
- R55 25 x 77mm
- Inner diameter: 25x57mm
- Color: black yellow
- Material: plastic
- Application: CNC machine tools, electronic equipment, fire machinery, stone machinery,
glass machinery, doors and window machinery, injection machines, robots, overweight transportation equipment, automated warehouses and so on.
Price 3000 Birr per meter
https://vector4engineering.com/product/drag-chain-r55/
Address – Megenagna, Zefmesh Grandmall 3rd floor 301
0993802995 Vector/0922787347 Kase
VECTOR FOUR ENGINEERING

Power Supplies
- Output 12V/10A and 24V/20A
- Input 200-240VAC/8.6A for the 24V/20A power supply
- Input 100-120VAC/2.4A or 200-240VAC/1.2A for the 12V/10A power supply
Price of 12V/10A power supply 6500 Birr
Price of 24V/20A power supply 10500 Birr
Address – Megenagna, Zefmesh Grandmall 3rd floor 301
0993802995 Vector/0922787347 Kase
VECTOR FOUR ENGINEERING

Power Supply Adjustable
- Output adjustable 5V/10A, 12V/5A and two 24V/14.6A
- Input 200-240VAC
Price 12500 Birr
Address – Megenagna, Zefmesh Grandmall 3rd floor 301
0993802995 Vector/0922787347 Kase
VECTOR FOUR ENGINEERING

RGB STRIP
- LED Type: SMD
- LEDs/m: 60
- Material: Flexible PCB
- Power per meter:4.8W/m
- Power Factor: 0.5
- Roll: 5m
- IP Class: IP65
- Input voltage: 12V
- Energy Consumption: 4.8/m kWh/1000h
- Color Designation: Warm White (WW), yellow, red, green and blue
- Dimmable: Yes
- Cuttable every 3 LEDs along the cutting marks
Price 1200 Birr
Address – Megenagna, Zefmesh Grandmall 3rd floor 301
0993802995 Vector Shop,0922787347 Kase/0924468599 Haben
VECTOR FOUR ENGINEERING

12V GEAR MOTOR
- Metal Gear Motor
- Rated Voltage: DC 12V
Price 3500 Birr
Address – Megenagna, Zefmesh Grandmall 3rd floor 301
0993802995 Vector Shop,0922787347 Kase/0924468599 Haben
VECTOR FOUR ENGINEERING

1.5M LINEAR RAIL AND HG15 BEARING BLOCKS
For 3D Printers, CNC machines, Advanced Industrial Systems etc.
Applications:
- CNC Precision machining
- Machines Heavy cutting machine
- Punching machines
- Marble cutting machines
- Automatic equipment
- Grinding machines
- High speed transfer equipments
- Injection moulding machines
Price of 1.5m Linear Rail with two bearing blocks 13500 Birr https://vector4engineering.com/product/1-5m-linear-rail/
Address – Megenagna, Zefmesh Grandmall 3rd floor 301
0993802995 Vector/0922787347 Kase
VECTOR FOUR ENGINEERING

1.5M LINEAR RAIL with 2 HGH20CA Blocks

Price 13,500 Birr

Address – Megenagna, Zefmesh Grandmall 3rd floor 301
0993802995 vector/0922787347

GEARED DC MOTOR
Operating voltage: 3V ~ 12V DC
Maximum torque: 800gf cm min (3V time)
Reduction Ratio: 1:48 (3V time)
Rotate Speed: 125rpm/min
Load Current: 70mA (250mA MAX) (3V time)
Price 650 Birr
https://vector4engineering.com/product/geared-dc-motor/
Address Megenagna Zefmesh Grandmall 3rd floor 301
0922787347 Kase/0924468599 Haben
VECTOR FOUR ENGINEERING

WHEEL
Center hole: 5.3mm x 3.66mm
Diameter: 66mm
Width: 2.66mm
Price 300 Birr
https://vector4engineering.com/product/wheel/
Address Megenagna Zefmesh Grandmall 3rd floor 301
0922787347 Kase/0924468599 Haben
VECTOR FOUR ENGINEERING

ROBOTIC CAR KIT
- Obstacle Avoiding Robotic Car using Arduino
Included components
- Arduino Uno
- 4 wheel robot car kit
- SG90 servo motor
- L293D motor control shield
- Ultrasonic Sensor Holder
- Ultrasonic sensor hc-sr04
- Jumper Wires 2 pack
- Battery Holder – 4 Cell
- AA Battery Cell 1.5V x 4
Price 11500 Birr
https://vector4engineering.com/product/robotic-car-kit/
Address – Megenagna, Zefmesh Grandmall 3rd floor 301
0993802995 Vector/0922787347 Kase
VECTOR FOUR ENGINEERING

BUCK CONVERTER HCW-P715
- Model: HCW-P715
- Input voltage: 9V – 36V DC
- Output voltage: 5V DC
Output Capability
- For 9V – 24V input, Ouput 5.2V/6A/30W
- For 24V – 32V input, Ouput 5.2V/5A/25W
- For 32V – 36V input, Ouput 5.2V/3.5A/18W
- High-power and stable output, which converts 12/24V DC to 5V DC.
- With the terminal block design, wiring is simple and convenient.
- The module has a USB output port which can be used to charge the phone and support fast charging.
Price 1250 Birr
https://vector4engineering.com/product/hcw-p715/
Address – Megenagna, Zefmesh Grandmall 3rd floor 301
0993802995 Vector/0922787347 Kase
VECTOR FOUR ENGINEERING

RACK AND PINION 1.25MOD
- 1.25 mod 22mm*25mm straight rack length 1400mm
- Model specifications: 1.25 mod
- 1.4m long
Price 18500Birr
Address – Megenagna, Zefmesh Grandmall 3rd floor 301
0993802995 Vector/0922787347 Kase
VECTOR FOUR ENGINEERING

SIM800L EVB GSM/GPRS MODULE
- Quad-band 850/900/1800/1900MHz
- Send and receive SMS messages
- Scan and receive FM radio broadcasts
- Lead out buzzer and vibrational motor control port
- AT command interface with “Auto baud” detection
- Supply Voltage: 3.7V ~ 5VDC
- Power Saving: Sleep mode 0.7mA (AT+CFUN=0)
- Frequency Bands: Quad-Band: GSM850, EGSM900, DCS1800, PCS1900
Transmitting Power
- Class 4 (2W) at GSM850, EGSM900
- Class 1 (1W) at DCS1800, PCS1900
GPRS Connectivity
- GPRS Multi-Slot Class 12 (Default)
- GPRS Multi-Slot Class 1-12 (Option)
Data GPRS
- GPRS Data down-link/up-link transfer max: 85.6 kbps
- Coding Scheme: CS-1, CS-2, CS-3 and CS-4
Price 1200 Birr
https://vector4engineering.com/product/sim800l-evb/
Address – Megenagna, Zefmesh Grandmall 3rd floor 301
0993802995 Vector/0922787347 Kase
VECTOR FOUR ENGINEERING

DM860H STEPPER MOTOR DRIVER
- Model Number : DM860H
- Power supply voltage DC24-110V or AC18-80V
- Can drive 4,6,8 line two-phase stepper motor
- Subdivision range: 400~25000
- Pulse response frequency: 200KHZ
- Driver current 2.4-7.2A, resolution: 0.1A
- Optically isolated signal input
- Motor noise optimization function
- It can drive any two-phase and four-phase hybrid stepping motor with a phase current of 2.0A or less
- 7.20KHz chopping frequency
- Overcurrent, overvoltage, under voltage, short circuit protection to insure safety operation.
Price 13500 Birr
https://vector4engineering.com/product/dm860h/
Address – Megenagna, Zefmesh Grandmall 3rd floor 301
0993802995 Vector/0922787347 Kase
VECTOR FOUR ENGINEERING
