Holding Pressure በInjection Molding ውስጥ ከሞልዱ ሙሉ ከተሞላ በኋላ ፕላስቲኩ ሲቀዘቅዝ የሚቀንሰውን መጠን ለመሙላት የሚጠቅም ግፊት ነው።"
2. Solenoid Valve እንዴት ይሰራል?
🎙️ "Solenoid Valve ኤሌክትሪክ ሲቀበል ኮይሉ ማግኔት ይሆናል። ይህም spool በማንቀሳቀስ የዘይት አቅጣጫን ይቀይራል።"
3. Proportional Valve እና Directional Valve ልዩነት
🎙️ "Directional Valve ኦን ወይም ኦፍ ብቻ ይሰራል። Proportional Valve ግን ፍሰትን እና ግፊትን በቀስታ ይቆጣጠራል።"
4. Clamp Force ምንድን ነው?
🎙️ "Clamp Force ማለት ሞልዱን በጥብቅ ለመዝጋት የሚያገለግል ኃይል ነው። ዝቅ ካለ Flash Defect ሊፈጠር ይችላል።"
5. Hydraulic Pressure ዝቅ ቢል ምን ይሆናል?
🎙️ "Hydraulic Pressure ዝቅ ሲል ሲሊንደሮች በትክክል አይንቀሳቀሱም፣ ማሽኑም ደካማ ይሰራል።"
6. Servo Motor ምንድን ነው?
🎙️ "Servo Motor ኃይል ለመቆጠብ እና ፍጥነትን በትክክል ለመቆጣጠር በዘመናዊ Injection Molding Machine ላይ ይጠቀማል።"
2. Solenoid Valve እንዴት ይሰራል?
🎙️ "Solenoid Valve ኤሌክትሪክ ሲቀበል ኮይሉ ማግኔት ይሆናል። ይህም spool በማንቀሳቀስ የዘይት አቅጣጫን ይቀይራል።"
3. Proportional Valve እና Directional Valve ልዩነት
🎙️ "Directional Valve ኦን ወይም ኦፍ ብቻ ይሰራል። Proportional Valve ግን ፍሰትን እና ግፊትን በቀስታ ይቆጣጠራል።"
4. Clamp Force ምንድን ነው?
🎙️ "Clamp Force ማለት ሞልዱን በጥብቅ ለመዝጋት የሚያገለግል ኃይል ነው። ዝቅ ካለ Flash Defect ሊፈጠር ይችላል።"
5. Hydraulic Pressure ዝቅ ቢል ምን ይሆናል?
🎙️ "Hydraulic Pressure ዝቅ ሲል ሲሊንደሮች በትክክል አይንቀሳቀሱም፣ ማሽኑም ደካማ ይሰራል።"
6. Servo Motor ምንድን ነው?
🎙️ "Servo Motor ኃይል ለመቆጠብ እና ፍጥነትን በትክክል ለመቆጣጠር በዘመናዊ Injection Molding Machine ላይ ይጠቀማል።"
Scanner card
With in an injection molding machine, a Scanner Card (also referred to as an I/O Scanner Module, Remote I/O Card, or Communication Card) is an electronic board that facilitates signal exchange between the PLC and field devices.
Primary Functions:
Inputs are read from the following components:
- Limit switches
- Proximity sensors
- Pressure switches
- Temperature controllers
- Safety switches
Outputs are sent to the following components:
- Solenoid valves
- Hydraulic valves
- Relays and contactors
- Motor drives
Operational Mechanism:
Sensors transmit signals to the Scanner Card. The Scanner Card conveys these signals to the PLC. The PLC processes the logic. The PLC subsequently transmits commands back through the Scanner Card. The Scanner Card then energizes the requisite output devices.
With in an injection molding machine, a Scanner Card (also referred to as an I/O Scanner Module, Remote I/O Card, or Communication Card) is an electronic board that facilitates signal exchange between the PLC and field devices.
Primary Functions:
Inputs are read from the following components:
- Limit switches
- Proximity sensors
- Pressure switches
- Temperature controllers
- Safety switches
Outputs are sent to the following components:
- Solenoid valves
- Hydraulic valves
- Relays and contactors
- Motor drives
Operational Mechanism:
Sensors transmit signals to the Scanner Card. The Scanner Card conveys these signals to the PLC. The PLC processes the logic. The PLC subsequently transmits commands back through the Scanner Card. The Scanner Card then energizes the requisite output devices.
In an injection molding machine 🏭, a Scanner Card (sometimes called an I/O Scanner Module, Remote I/O Card, or Communication Card) is an electronic board that exchanges signals between the PLC and field devices 🔄.
Main Functions ⚙️
Reads inputs from:
Limit switches 🛑
Proximity sensors 🔍
Pressure switches ⏱️
Temperature controllers 🌡️
Safety switches 🛡️
Sends outputs to:
Solenoid valves 💧
Hydraulic valves 🛢️
Relays and contactors ⚡
Motor drives 🏎️
How it Works
Sensors send signals to the scanner card.
The scanner card transfers these signals to the PLC.
The PLC processes the logic.
The PLC sends commands back through the scanner card.
The scanner card energizes the required output devices.
Symptoms of a Faulty Scanner Card
Inputs not changing on the HMI even though sensors are working.
Solenoid valves not energizing.
Communication errors between PLC and remote I/O.
Machine alarms related to I/O or fieldbus communication.
LEDs on the card showing fault or communication loss.
Typical Location
The scanner card is usually found:
Inside the electrical control cabinet.
Mounted near the PLC rack.
Sometimes in a remote I/O box near the machine's hydraulic valves.
Main Functions ⚙️
Reads inputs from:
Limit switches 🛑
Proximity sensors 🔍
Pressure switches ⏱️
Temperature controllers 🌡️
Safety switches 🛡️
Sends outputs to:
Solenoid valves 💧
Hydraulic valves 🛢️
Relays and contactors ⚡
Motor drives 🏎️
How it Works
Sensors send signals to the scanner card.
The scanner card transfers these signals to the PLC.
The PLC processes the logic.
The PLC sends commands back through the scanner card.
The scanner card energizes the required output devices.
Symptoms of a Faulty Scanner Card
Inputs not changing on the HMI even though sensors are working.
Solenoid valves not energizing.
Communication errors between PLC and remote I/O.
Machine alarms related to I/O or fieldbus communication.
LEDs on the card showing fault or communication loss.
Typical Location
The scanner card is usually found:
Inside the electrical control cabinet.
Mounted near the PLC rack.
Sometimes in a remote I/O box near the machine's hydraulic valves.
Check valve
check valve (also called a non-return valve) allows fluid (oil, water, air) to flow in one direction only and blocks flow in the opposite direction. 🛑💧
Main Functions of a Check Valve
* Prevents backflow 🔄
Stops hydraulic oil from flowing backward when pressure drops.
* Maintains pressure 📈
Keeps pressure trapped in a hydraulic circuit or actuator.
* Protects components 🛡️
Prevents reverse flow that could damage pumps, valves, and cylinders.
* Holds actuator position 🛑
In hydraulic cylinders, it can help prevent the cylinder from drifting when the pump is stopped.
In an Injection Molding Machine 🏭
A check valve is commonly found:
* In the hydraulic system to prevent reverse oil flow.
* At the screw tip (non-return ring/check ring) to prevent molten plastic from flowing backward during injection. 🍦🔧
check valve (also called a non-return valve) allows fluid (oil, water, air) to flow in one direction only and blocks flow in the opposite direction. 🛑💧
Main Functions of a Check Valve
* Prevents backflow 🔄
Stops hydraulic oil from flowing backward when pressure drops.
* Maintains pressure 📈
Keeps pressure trapped in a hydraulic circuit or actuator.
* Protects components 🛡️
Prevents reverse flow that could damage pumps, valves, and cylinders.
* Holds actuator position 🛑
In hydraulic cylinders, it can help prevent the cylinder from drifting when the pump is stopped.
In an Injection Molding Machine 🏭
A check valve is commonly found:
* In the hydraulic system to prevent reverse oil flow.
* At the screw tip (non-return ring/check ring) to prevent molten plastic from flowing backward during injection. 🍦🔧
Types of hydraulic valves and functions 🛠️
1. Directional Control Valve (DCV) 🔄
Function:
Controls the direction of oil flow.
Starts, stops, and reverses cylinder or motor movement.
Examples: 2/2, 3/2, 4/2, 4/3 valves.
2. Pressure Relief Valve 🛡️
Function:
Protects the system from excessive pressure.
Opens when pressure exceeds the set value and returns oil to the tank.
3. Pressure Reducing Valve 📉
Function:
Maintains a lower pressure in a specific circuit.
Used when one section needs less pressure than the main system.
4. Sequence Valve ⏱️
Function:
Ensures one operation occurs before another.
Example: Cylinder A extends before Cylinder B.
5. Counterbalance Valve ⚖️
Function:
Prevents a load from falling due to gravity.
Common on vertical cylinders.
6. Check Valve (Non-Return Valve) ➡️
Function:
Allows oil flow in one direction only.
Prevents reverse flow.
7. Pilot-Operated Check Valve 🔒
Function:
Locks a cylinder in position.
Opens only when pilot pressure is applied.
8. Flow Control Valve 🌊
Function:
Controls oil flow rate.
Adjusts cylinder speed or motor speed.
9. Proportional Valve 📊
Function:
Provides precise control of flow or pressure.
Output changes proportionally to the electrical signal.
10. Servo Valve 🎯
Function:
Very high-precision control of position, speed, and pressure.
Used in advanced injection molding and automation systems.
11. Cartridge Valve 🔩
Function:
Compact valve inserted into a manifold block.
Handles high flow rates.
12. Safety Valve ⚠️
Function:
Protects equipment and personnel from dangerous overpressure conditions.
Similar purpose to a relief valve but often used in pressure vessels.
1. Directional Control Valve (DCV) 🔄
Function:
Controls the direction of oil flow.
Starts, stops, and reverses cylinder or motor movement.
Examples: 2/2, 3/2, 4/2, 4/3 valves.
2. Pressure Relief Valve 🛡️
Function:
Protects the system from excessive pressure.
Opens when pressure exceeds the set value and returns oil to the tank.
3. Pressure Reducing Valve 📉
Function:
Maintains a lower pressure in a specific circuit.
Used when one section needs less pressure than the main system.
4. Sequence Valve ⏱️
Function:
Ensures one operation occurs before another.
Example: Cylinder A extends before Cylinder B.
5. Counterbalance Valve ⚖️
Function:
Prevents a load from falling due to gravity.
Common on vertical cylinders.
6. Check Valve (Non-Return Valve) ➡️
Function:
Allows oil flow in one direction only.
Prevents reverse flow.
7. Pilot-Operated Check Valve 🔒
Function:
Locks a cylinder in position.
Opens only when pilot pressure is applied.
8. Flow Control Valve 🌊
Function:
Controls oil flow rate.
Adjusts cylinder speed or motor speed.
9. Proportional Valve 📊
Function:
Provides precise control of flow or pressure.
Output changes proportionally to the electrical signal.
10. Servo Valve 🎯
Function:
Very high-precision control of position, speed, and pressure.
Used in advanced injection molding and automation systems.
11. Cartridge Valve 🔩
Function:
Compact valve inserted into a manifold block.
Handles high flow rates.
12. Safety Valve ⚠️
Function:
Protects equipment and personnel from dangerous overpressure conditions.
Similar purpose to a relief valve but often used in pressure vessels.
Injection Molding Machines Commonly Use:
Directional Control Valves (DCV)
Pressure Relief Valves
Flow Control Valves
Check Valves
Proportional Valves
Cartridge Valves
Directional Control Valves (DCV)
Pressure Relief Valves
Flow Control Valves
Check Valves
Proportional Valves
Cartridge Valves
Hydraulic injection molding machine electrical parts ⚙️💡
In a hydraulic machine (such as an injection molding machine), the main electrical parts and their functions are:
Electrical Part | Function
--- | ---
Main Motor ⚡ | Drives the hydraulic pump to generate hydraulic pressure and flow.
Contactor 🔄 | Switches the motor ON and OFF from the control circuit.
Overload Relay 🛡️ | Protects the motor from excessive current and overheating.
Circuit Breaker (MCB/MCCB) 🔌 | Protects the electrical system from short circuits and overloads.
PLC (Programmable Logic Controller) 🤖 | Controls machine sequences and processes based on inputs and programs.
Power Supply Unit (24VDC) 🔋 | Converts AC voltage to DC voltage for sensors and control circuits.
Solenoid Valve Coil 🧲 | Converts electrical signals into magnetic force to shift hydraulic valves.
Proportional Valve Amplifier Card 🎛️ | Controls proportional valves by regulating current to the valve coil.
Sensors (Pressure, Temperature, Position) 🌡️📏 | Monitor machine conditions and send signals to the PLC.
Limit Switches 🛑 | Detect end positions of moving parts.
Encoder 📊 | Measures motor rotation, speed, or position.
HMI (Human Machine Interface) 🖥️ | Touch screen used by operators to set parameters and monitor machine status.
Relay 🔗 | Electrically switches control circuits.
SSR (Solid State Relay) ⚡ | Electronic switching device with no moving contacts.
Emergency Stop Switch 🚨 | Immediately stops machine operation for safety.
Indicator Lamps 💡 | Show machine status such as Power ON, Alarm, or Running.
Typical Hydraulic-Electrical System 🔄
Signal flow: Sensor → PLC → Relay/Amplifier Card → Solenoid Valve → Hydraulic Valve → Hydraulic Cylinder/Motor
In a hydraulic machine (such as an injection molding machine), the main electrical parts and their functions are:
Electrical Part | Function
--- | ---
Main Motor ⚡ | Drives the hydraulic pump to generate hydraulic pressure and flow.
Contactor 🔄 | Switches the motor ON and OFF from the control circuit.
Overload Relay 🛡️ | Protects the motor from excessive current and overheating.
Circuit Breaker (MCB/MCCB) 🔌 | Protects the electrical system from short circuits and overloads.
PLC (Programmable Logic Controller) 🤖 | Controls machine sequences and processes based on inputs and programs.
Power Supply Unit (24VDC) 🔋 | Converts AC voltage to DC voltage for sensors and control circuits.
Solenoid Valve Coil 🧲 | Converts electrical signals into magnetic force to shift hydraulic valves.
Proportional Valve Amplifier Card 🎛️ | Controls proportional valves by regulating current to the valve coil.
Sensors (Pressure, Temperature, Position) 🌡️📏 | Monitor machine conditions and send signals to the PLC.
Limit Switches 🛑 | Detect end positions of moving parts.
Encoder 📊 | Measures motor rotation, speed, or position.
HMI (Human Machine Interface) 🖥️ | Touch screen used by operators to set parameters and monitor machine status.
Relay 🔗 | Electrically switches control circuits.
SSR (Solid State Relay) ⚡ | Electronic switching device with no moving contacts.
Emergency Stop Switch 🚨 | Immediately stops machine operation for safety.
Indicator Lamps 💡 | Show machine status such as Power ON, Alarm, or Running.
Typical Hydraulic-Electrical System 🔄
Signal flow: Sensor → PLC → Relay/Amplifier Card → Solenoid Valve → Hydraulic Valve → Hydraulic Cylinder/Motor
